Model Name : N-BioAccess

Storage Capacity
Finger Capacity: 10,000
Card Capacity: 10,000
Max Users: 10,000
Password: 10,000
Log Capacity: 2,00,000
Features:
High-Speed and Accurate Fingerprint Identification
Fingerprint, Card, Password authentication
Output relay for door open.
Supremely low Electric energy consumption.
Highly reliable and durable.
Comprehensive software development kit(SDK) is available for development and integration.
Communication Interface
Communication: WIFI, RS 485, TCP/IP, USB
Biometric
Push Data YES
Sensor type 500 DPI
FAR: 0.00001%
FRR 0.001%
OS Linux
Verification Time : less than equal to 1 second
RF card options:125kHz EM /13.56MHz Mifare (Optional)
WiFi, RS485, TCP/IP, USB

Audio/Visual
LCD: 2.8" TFT color screen
Voice instruction: 16-bit Hi-Fi voice & sound indication.
Language: English
Keypad Feather Touch Keypad

Access control
Wiegand in & out : YES
Relay : YES
Anti Passback YES
Access Control
Support Reader: RS485 Reader, Wiegand Reader, Exit Switch, Remote, No Touch

Power & Environment
Operating Temperature: 0°C~50°c
Power: 12V DC/2A
Dimension (L*H*W) :75 x 200 x 35 mm

Utility: A smart lock is an electromechanical lock that is designed to perform locking and unlocking operations on a door when it receives a prompt via an electronic keypad, biometric sensor, access card, Bluetooth, or Wi-FI from a registered mobile device.
Useful for: Home, Corporate Office, etc....
