Micro-controller Based
1 Message
Can Store 7 Telephone Numbers
20 Second Recording Time for Message
Message Playback for Recorded Messages
13 Key Backlit Keypad
4 Digit User Code to Arm, Disarm and Enter Programming Mode
Telephone Number Check
Non-volatile Memory Restores Select Programmable Settings in Case of System Reset
Operates With Both Tone & Pulse
Power, Dialing and Program Status Leds
Self Test on Power Up/ Power Reset
Line Overriding to Use Line and Disable Connected Instruments
Audio Indication for Arm and Disarm
In-built Tamper Switch
Premium White Abs Housing

Technical Specification
ELECTRICAL
Operating Voltage: 12V & 24V DC
Quiescent Current: 50ma
Current With Dialing & Message Play: 150ma
ENVIRONMENTAL
Operating Temperature: 0c to 45C
Storage Temperature: -20C to 60C
Maximum humidity: 95% Non-Condensing
Environment: Residential / Commercial / Light Industrial
PHYSICAL
Dimensions: 199 mm x 110mm x 4 5mm
Warranty:- 1 Year
