Features:
•Stabe performance,8 Zones.
•Sournd and Light alarm
. •System Sensitivity
Characteristics & Functions
: • There are 8 pinpoint zones of the door frame.
• Based on Auto-set microcontroller.
• Operational frequency can be adjusted manually and automatically.
• Sensitivity of each zone from O to 200.
• Alarm and pass/reverse counter facility available.
• Detects all types of Metals.
• Security levelup to 100 levels.
• Self-calibration starts once powered ON.
• Freq,uency level up to SOlevels.
• Detection Technology - Even detection technology.
• Waterproof mica pasted on panel & provided ABS plastic boot top bottom (IP 65 Protected).
• Variousdetection occasions can set sensitivity as per location.
• Harmless to the human body (Heart Pacemaker,Pregnant Women, Magnetic Floppy, Recording Tape etc.
• Working standby:16 high brightness LED indicator ON.
• Detection speed:More than 60 people pass & detectin 1Minute.
Technical Parameter
• NABL Tested (Government Approved Lab)
• Dimensions:approx 2240mm (h) x 840mm (w) X 650mm (d) ±5%.
• Net wt.:Around 67 kgs.
• Power:230V,50/60Hz.
• Humidity:95% Non-condensing.
• Workplace Environment: - 2o•c to ss•c.
