AUTOMATIC SPIKE BARRIER
Makie:Mcvick
Width:4 Meter
SPIKE MADE UP OF TAMPERED STEEL OF HEIGHT OF 150 MM
SPACED MAXIMUM 100MM CENTER TO CENTER
CAPABLE OF TAKING IMPACT LOAD OF 20 , 50, 80, AND 100 TON TRUCK
MOUNTED ON MS CHANNEL (I SECTION) OF SUITABLE THICKNESS
IN THE LOWERED POSITION THE TYRE KILLER IS FLUSH WITH THE ROAD SURFACE THUS COMPLETELY INCONSPICUOUS THE COVER PLATE OF THE TYRE STRIPPER/ SPIKE BARRIER IS CONSTRUCTED IN ACCORDANCE WITH BRIDGE CLASS 60/30 (DIN 1072) ALLOWING EVEN THE HEAVIEST VEHICLES (ALMOST 75 TONS) TO ENTER THE SECURED AREA
MASSIVE STEEL STATIC AND RISING IMPACT FRAMES,CONTINUOUSLY WELDED SEAMS FOR MAXIMUM STRENGTH.
SEPARATE ROAD-SURFACE TRIMMER FRAME FOR EASE OF INSTALLATION / MINIMUM SITE DISTRUPTION MANUAL UNLOCKING DEVICE WITH PERSONLIZED KEY
CAN BE INTERFACED WITH REMOTE CONTROL, VEHICLE LOOP DETECTOR PUSH BUTTON, SENSORS ETC.
POWER SUPPLY VOLTAGE: 220V/50 Hz OR 440VOLT 3 PHASE
OPERATING FREQUENCY: 60%
THERMAL CUTOUT: 140 DEG.
OPERATING TEMPRATURE: -20 TO +60 DEG.
OPENNING TIME: 1-2 SECONDS
