Product Information

Attribute

Value

Height

75mm

Material

PVC, Rubber

Channel

3 Channel

Length

900 MM

Cable Protector 3 Channel Height 75MM

KTI160040013CH8

Product Description

Heavy-duty 3-channel modular cable protector designed for managing and safeguarding electrical cables, hoses, and wiring from pedestrian foot traffic and vehicular load.

Brand: Axnoy
Product Reference: KTI160040013CH8
Channel Configuration: 3 Channels
Overall Dimensions: 900 mm (Length) x 480 mm (Width) x 75 mm (Height)
Base Material: Heavy-duty vulcanized Rubber
Flap / Lid Material: Molded PVC and Plastic
Opening Mechanism: Hinged top flap for easy top-loading cable placement
Interlocking Feature: Built-in male/female modular end connectors for continuous runs
Application: Cable and hose protection in manufacturing units, warehouses, construction sites, and commercial facilities

KTI160040013CH8

Price

₹ 3,429.00 excl. GST

+ 18.00% Tax + Freight Charge

If you are an existing KTI Customer, Sign In to view your special price

Product Details
Available Brands	Axnoy
Unit	Numbers
HSN Code	39269099
Dimension	L 90 x W 48 x H 7.5 cm cm ft in m
Warranty	Not Applicable
Resources	Download Datasheet
Tags/categories	Safety Road Traffic Safety Solutions Cable Protector

Usually dispatched within 4 days

About this product .

The 3-Channel Cable Protector provides reliable mechanical defense and routing organization for electrical conduits, signal wires, and industrial hoses. Engineered for rigorous plant and facility environments, it shields exposed cables from crushing under heavy vehicular movement and foot traffic while eliminating severe trip hazards.
Constructed with a heavy-duty vulcanized rubber base and a durable molded PVC top flap, this cable ramp delivers high impact resistance and long-lasting structural rigidity. The flexible yet robust rubber base conforms smoothly to pavement and floor irregularities while dampening acoustic noise during vehicle transit.
Featuring dimensions of 900 mm in length, 480 mm in width, and a profile height of 75 mm, the protector accommodates multiple thick power leads across three segregated internal raceways. This separation prevents physical chafing, entangling, and potential signal interference between parallel cable lines.
A hinged top-loading flap system allows maintenance crews to lay, inspect, and extract cables quickly without unthreading long lines. The unit integrates standard interlocking modular end connectors, enabling quick daisy-chaining across extensive spans such as warehouse aisles, loading bays, and event stages.
The ramped incline ensures smooth vehicle crossover and minimises impact shock for passing trolleys, forklifts, and utility vehicles. Textured anti-slip surface ribs on the upper lid provide positive foot traction to safeguard personnel in wet or dusty industrial environments.
Designed for deployment across industrial manufacturing floors, logistics hubs, workshop service bays, outdoor temporary power runs, and exhibition arenas, this cable protector requires zero floor anchoring for standard modular runs and remains easily washable with standard water sprays.

Product Information .

Industries, Factories Hospitals, Clinics Shopping Malls, Showrooms Public Roads Conference Rooms Construction, Builder Projects Server Rooms Basement, Parking Areas Construction Sites

Installation and Deployment Guide for Axnoy 3-Channel Cable Protector Ramp

Proper deployment of the Axnoy 3-channel cable protector ramp (SKU: KTI160040013CH8) ensures immediate mechanical protection for exposed utility lines while maintaining safe transit pathways across industrial, commercial, and temporary environments. The unit features dimensions of 900 mm in length, 480 mm in width, and an overall height profile of 75 mm.

Surface Preparation and Layout Planning

Before placing the ramp, inspect and prepare the designated transit corridor. The mounting surface should be cleared of loose debris, industrial scrap, tools, and standing liquids to provide continuous contact with the heavy-duty rubber base. Identify the exact path of electrical lines, communication cables, or utility conduits to ensure the 900 mm unit length covers the complete exposure zone, or plan for multiple consecutive units placed in series for extended spans.

Base Placement via Surface-Mounted Drop-Over Design

The Axnoy cable protector utilizes a surface-mounted drop-over ramp design engineered for rapid placement directly over target floor areas:

Position the heavy-duty rubber base flat against the floor or ground surface across the intended traffic crossing.
Orient the 480 mm width perpendicular to the direction of crossing traffic to present a stable approach toward the 75 mm center height.
Ensure the base rests level without rocking over uneven ground joints, curb transitions, or floor seams.

Top-Loading Cable Routing into 3 Channels

The unit features a top-opening hinged flap fabricated from a PVC and plastic composite, eliminating the need to pull or fish continuous wire runs through closed channels:

Lift the hinged PVC and plastic flap upward to fully open the top section and access the 3 internal routing channels.
Lay cables directly into the channels from above (top-loading configuration).
Distribute lines across the 3 separate channels to isolate industrial electrical lines from data/communication wiring and secondary utility conduits.
Ensure all conductors rest entirely within the channel cavities below the upper rim to prevent pinching during closure.

Flap Closure and Final Inspection

Lower the composite flap downward until it rests flush against the heavy-duty rubber base structure across the entire 900 mm length. Visually verify that no cabling is caught between the lid edges and the channel dividing walls. Inspect the top surface to confirm a continuous, even profile across the 75 mm crest before subjecting the installation to foot or vehicle movement.

Application-Specific Deployment Contexts

Facility Type	Deployment Location	Target Cable Types
Industrial & Construction	Manufacturing plants, factories, builder sites	Heavy industrial electrical supply lines and utility conduits
Traffic & Parking	Basements, parking lots, driveways, public road crossings	Temporary power runs and surface utility crossings
Commercial & Institutional	Shopping malls, showrooms, clinics, hospitals	Temporary utility wiring, display electrical feeds, maintenance cabling
Temporary Operations	Conference rooms, server rooms, project offices	Communication cables, server network lines, audio-visual feeds

Industrial and Commercial Application Scenarios

Industrial Manufacturing Plants and Active Construction Sites

In heavy industrial environments, fabrication plants, and construction builder projects, floor-level wiring is subjected to physical strain from personnel, carts, and moving operational equipment. The Axnoy 3-channel rubber cable protector ramp (SKU: KTI160040013CH8) provides floor-level segregation and mechanical shielding for standard industrial electrical power lines, utility conduits, and temporary machinery hookups across high-traffic pathways.

The 75 mm height profile combined with a 480 mm ramp width and a solid rubber base ensures stable surface-mounted placement directly over plant floors. The top-opening hinged flap made of PVC and plastic allows plant safety managers and site engineers to drop in heavy-gauge power feeds and pneumatic or utility conduits from above, eliminating the need to thread lines through closed sleeves during rapid machinery retooling.

Basements, Driveways, and Vehicle Crossing Areas

Managing vehicular cross-traffic over exposed wiring is critical in basements, multi-level parking structures, access driveways, and road crossing checkpoints. The 900 mm modular length provides straight-line containment to bridge cables across vehicle approach ramps and loading bays. Its heavy-duty rubber foundation provides substantial floor contact to prevent shifting as vehicles traverse the ramp surface.

By routing power distribution lines and facility management wiring through the three isolated channels, facility operators can maintain continuous vehicle flow while protecting vital building infrastructure lines from direct tire compression and external abrasion.

Commercial Facilities, Healthcare Centers, and Retail Showrooms

Public-facing and commercial facilities require orderly cable management to maintain safety standards and eliminate trip hazards. The Axnoy cable protector is engineered for deployment across high-footfall zones in commercial shopping malls, automobile showrooms, medical clinics, and hospital utility corridors.

The surface-mounted drop-over design enables facility teams to run power extensions, temporary lighting cables, and sanitation equipment wiring across main pedestrian concourses without restricting access or damaging underlying floor finishes.

Temporary Event Deployments, Server Rooms, and Office Infrastructure

For temporary setups such as corporate conference halls, IT server rooms, and modular builder site offices, cabling layouts change frequently. The top-loading PVC and plastic composite flap enables fast reconfiguration of communication cables, data patch cords, and temporary electrical feeds without disassembling the entire ramp run.

Sector Application Summary

Manufacturing & Heavy Industry: Isolates primary plant power supplies, secondary machine lines, and utility tubing.
Logistics & Parking Facilities: Shields underground basement wiring and driveway crossing conduits from moving wheels.
Commercial & Public Venues: Safeguards retail shoppers, clinic staff, and showroom visitors from exposed floor cables.
IT & Temporary Projects: Provides fast top-loading channel access for network cabling and temporary project distribution.

Related Products .

Page 1 of 4

Syncing...

Compare with similar products .

	Current Product Cable Protector 3 Channel Height 75MM	Cable Protector 5 Channel Height 50MM	Cable Protector 1 Channel Height 50MM	+ Add product to compare
SKU	KTI160040013CH8	KTI160040015CH5	KTI16004001C120	—
Brand	Axnoy	Axnoy, H2, KTI	H2	—
Price (excl. GST)	₹ 3,429.00 excl. GST	₹ 3,753.00 excl. GST	₹ 2,268.00 excl. GST	—
GST %	18.00%	18.00%	18.00%	—
Channel	3 Channel	5 Channel	1 Channel	—
Height	75mm	50mm	50mm	—
Material	PVC - Rubber	PVC	PVC	—
Certifications	—	—	—	—
Availability	Made to Order	Made to Order	In Stock	—
				—

Category FAQ .

Cable Protector

A cable protector, also known as a cable ramp or cable cover, is a device designed to protect cables, hoses, and wires from damage caused by pedestrian or vehicular traffic. It provides a safe and organized way to route and secure cables in areas where they are exposed and prone to potential tripping hazards or accidental damage.

Using cable protectors offers several benefits, including: Safety: Cable protectors help prevent tripping accidents by keeping cables neatly organized and out of the way of foot traffic or vehicles. Cable protection: They provide a physical barrier to shield cables from being stepped on, crushed, or damaged by heavy vehicles or equipment. Easy installation: Cable protectors are typically lightweight and easy to install. They often feature modular designs that allow for quick setup and reconfiguration as needed. Durability: They are made from sturdy materials, such as rubber or polyurethane, which can withstand heavy loads, extreme weather conditions, and frequent use. Versatility: Cable protectors come in various sizes, shapes, and load capacities to accommodate different cable types and traffic volumes. They can be used indoors or outdoors, in temporary or permanent installations.

Cable protectors can be used in a wide range of settings, including: Events and exhibitions: Cable protectors help manage and protect cables used for audio, video, and lighting setups in concert venues, trade shows, and conferences. Construction sites: They are used to secure cables and wires used for power distribution, temporary lighting, or equipment operation in construction zones. Industrial facilities: Cable protectors are employed in manufacturing plants, warehouses, and distribution centers to safeguard cables running across floors or aisles where forklifts, pallet jacks, or other vehicles operate. Public areas: They can be installed in shopping malls, airports, train stations, or public walkways to ensure the safety of pedestrians and prevent tripping hazards caused by exposed cables.

Road Traffic Safety Solutions

Traffic Safety Products, Road Safety Solutions, Traffic Management Systems, Highway Safety Equipment, Road Safety Gear, Traffic Control Devices, Vehicle Safety Solutions, Road Signage Solutions, Safety Barriers and Cones, Traffic Signal Systems, Roadway Safety Solutions, Pedestrian Safety Equipment, Traffic Warning Systems, Vehicle Detection Solutions, Traffic Safety Accessories.

Road/traffic safety solutions refer to measures and products designed to improve safety for road users, including drivers, pedestrians, and cyclists. These solutions aim to reduce accidents, injuries, and fatalities on roadways by addressing various aspects of traffic management, visibility, and infrastructure.

Road/traffic safety solutions are important for several reasons: Accident prevention: They help to prevent accidents and minimize the severity of injuries by implementing effective safety measures on roadways. Protecting vulnerable road users: Safety solutions prioritize the safety of pedestrians, cyclists, and other vulnerable road users who are at higher risk of accidents. Efficient traffic management: They contribute to smoother traffic flow, reducing congestion and improving overall transportation efficiency. Compliance with regulations: Many road/traffic safety solutions are mandated by traffic regulations and standards to ensure compliance and the well-being of road users.

There are several common road/traffic safety solutions used worldwide. These include: Road signs and markings: Clear and visible signs, traffic signals, and road markings provide guidance, warnings, and instructions to drivers and pedestrians. Speed management: Speed limit enforcement, speed bumps, and speed cameras help control vehicle speeds and reduce the risk of accidents. Traffic calming measures: Techniques such as road humps, roundabouts, chicanes, and narrowed lanes are used to slow down traffic and create safer environments for pedestrians and cyclists. Pedestrian safety measures: Pedestrian crossings, sidewalks, footbridges, and pedestrian-friendly infrastructure improve safety and accessibility for pedestrians. Cycling infrastructure: Bike lanes, dedicated paths, and bicycle-friendly intersections promote safe cycling and separate cyclists from vehicle traffic. Traffic control devices: Traffic lights, stop signs, yield signs, and intersection controls ensure orderly and safe movement of vehicles. Road barriers and guardrails: These provide protection and prevent vehicles from crossing into opposing lanes or off the road. Intelligent transportation systems (ITS): Advanced technologies, such as traffic cameras, variable message signs, and smart traffic management systems, enhance traffic flow and provide real-time information to drivers. Roadway lighting: Proper lighting along roadways improves visibility, especially during nighttime, reducing the risk of accidents. Driver education and awareness campaigns: Public awareness programs, educational initiatives, and driver training aim to promote responsible driving behavior and awareness of road safety practices.

Road/traffic safety solutions have proven to be effective in reducing accidents, injuries, and fatalities on roadways. The effectiveness of specific solutions may vary depending on various factors, such as their proper implementation, compliance by road users, and ongoing evaluation and improvement. Continuous monitoring, data analysis, and research contribute to the development of more effective safety measures and interventions.
