What is the product Cable Protector also known as? Cable Cover, Cable Ramp, Cord Protector, Wire Protector, Cable Management Ramp, Electrical Cable Cover, Wire Management Protector, Cable Pathway, Floor Cable Protector, Cord Safety Ramp, Heavy-Duty Cable Protector, Cable Guard, Power Cord Protector, Safety Cable Cover, Cable Shield Q: What is a cable protector?

A cable protector, also known as a cable ramp or cable cover, is a device designed to protect cables, hoses, and wires from damage caused by pedestrian or vehicular traffic. It provides a safe and organized way to route and secure cables in areas where they are exposed and prone to potential tripping hazards or accidental damage.

What are the benefits of using cable protectors?

Using cable protectors offers several benefits, including: Safety: Cable protectors help prevent tripping accidents by keeping cables neatly organized and out of the way of foot traffic or vehicles. Cable protection: They provide a physical barrier to shield cables from being stepped on, crushed, or damaged by heavy vehicles or equipment. Easy installation: Cable protectors are typically lightweight and easy to install. They often feature modular designs that allow for quick setup and reconfiguration as needed. Durability: They are made from sturdy materials, such as rubber or polyurethane, which can withstand heavy loads, extreme weather conditions, and frequent use. Versatility: Cable protectors come in various sizes, shapes, and load capacities to accommodate different cable types and traffic volumes. They can be used indoors or outdoors, in temporary or permanent installations.

Where can cable protectors be used?

Cable protectors can be used in a wide range of settings, including: Events and exhibitions: Cable protectors help manage and protect cables used for audio, video, and lighting setups in concert venues, trade shows, and conferences. Construction sites: They are used to secure cables and wires used for power distribution, temporary lighting, or equipment operation in construction zones. Industrial facilities: Cable protectors are employed in manufacturing plants, warehouses, and distribution centers to safeguard cables running across floors or aisles where forklifts, pallet jacks, or other vehicles operate. Public areas: They can be installed in shopping malls, airports, train stations, or public walkways to ensure the safety of pedestrians and prevent tripping hazards caused by exposed cables.

Product Information

Attribute

Value

Height

50mm

Material

PVC

Channel

3 Channel

Cable Protector 3 Channel 50MM Height with Rubber Base and Hinged Top Flap

Cable Protector 3 Channel Height 50MM

KTI160040013CHP

Product Description

Heavy-duty 3-channel floor cable protector designed to safeguard electrical cables, hoses, and wiring conduits from vehicular and pedestrian traffic.

Product Type: 3-Channel Cable Protector Ramp
Base Material: Vulcanised Rubber Base
Flap Material: PVC and Hard Plastic Hinged Top Cover
Overall Length: 1000 mm (100 cm)
Overall Width: 300 mm (30 cm)
Overall Height: 50 mm (5.0 cm)
Channel Dimensions: 35 mm (Width) x 30 mm (Height) per channel
Number of Channels: 3 Channels
Placement / Mounting: Floor / Road Surface Modular Placement

KTI160040013CHP

4.7

3 ratings

Price

₹ 2,214.00 excl. GST

+ 18.00% Tax + Freight Charge

If you are an existing KTI Customer, Sign In to view your special price

Product Details
Available Brands	H2, Axnoy
Unit	Numbers
HSN Code	39269099
Weight	6 kg
Dimension	L 100 x W 30 x H 5 cm cm ft in m
Warranty	Not Applicable
Tags/categories	Safety Road Traffic Safety Solutions Cable Protector

Order within 10 hrs 22 mins

1.00 Nos Ready in Stock Dispatched by Today, Thu, 10th September

Customer reviews

4.7 out of 5

3 global ratings

5 star

67%

4 star

33%

3 star

2 star

1 star

No customer reviews yet. Be the first to share your experience.

Deployment Environment	Protected Utility Types	Primary Operational Purpose
Manufacturing & Assembly	Power feeds, pneumatic hoses, control wiring	Impact shielding against plant traffic & cart wheels
Warehouses & Logistics	Motor cables, barcode reader runs, power drops	Ramp crossing for hand trucks and pedestrian safety
Construction & Civil Works	Heavy-duty temporary power cords, compressor lines	Abrasion resistance and rapid top-drop cable access
Stage, AV & Trade Shows	DMX lines, multicore audio snakes, lighting runs	Tripping hazard prevention across public walkways
Parking & Facility Basements	Drainage lines, temporary lighting feeds, conduits	Controlled vehicle transition across utility lines

Deployment Environment

Protected Utility Types

Primary Operational Purpose

Manufacturing & Assembly

Power feeds, pneumatic hoses, control wiring

Impact shielding against plant traffic & cart wheels

Warehouses & Logistics

Motor cables, barcode reader runs, power drops

Ramp crossing for hand trucks and pedestrian safety

Construction & Civil Works

Heavy-duty temporary power cords, compressor lines

Abrasion resistance and rapid top-drop cable access

Stage, AV & Trade Shows

DMX lines, multicore audio snakes, lighting runs

Tripping hazard prevention across public walkways

Parking & Facility Basements

Drainage lines, temporary lighting feeds, conduits

Controlled vehicle transition across utility lines

	Current Product Cable Protector 3 Channel Height 50MM	Cable Protector 4 Channel Height 60MM	Cable Protector 5 Channel Height 50MM	+ Add product to compare
SKU	KTI160040013CHP	KTI160040014CH5	KTI160040015CH5	—
Brand	Axnoy, H2	KTI	Axnoy, H2, KTI	—
Price (excl. GST)	₹ 2,214.00 excl. GST	₹ 3,618.00 excl. GST	₹ 3,753.00 excl. GST	—
GST %	18.00%	18.00%	18.00%	—
Channel	3 Channel	4 Channel	5 Channel	—
Height	50mm	60mm	50mm	—
Material	PVC	PVC	PVC	—
Certifications	—	—	—	—
Availability	In Stock	In Stock	Made to Order	—
				—

Current Product

Cable Protector 3 Channel Height 50MM

Cable Protector 4 Channel Height 60MM

Cable Protector 5 Channel Height 50MM

+ Add product to compare

SKU

KTI160040013CHP

KTI160040014CH5

KTI160040015CH5

—

Brand

Axnoy, H2

KTI

Axnoy, H2, KTI

—

Price (excl. GST)

₹ 2,214.00 excl. GST

₹ 3,618.00 excl. GST

₹ 3,753.00 excl. GST

—

GST %

18.00%

—

Channel

3 Channel

4 Channel

5 Channel

—

Height

50mm

60mm

50mm

—

Material

PVC

—

Certifications

—

Availability

In Stock

Made to Order

—
