Product Information

Attribute

Value

Height

45mm

Channel

2 Channel

Material

PVC

Heavy duty 2 channel rubber and plastic cable protector 45mm height

Cable Protector 2 Channel Height 45MM

KTI160040012CHP

Product Description

Heavy-duty 2-channel rubber and plastic cable protector designed to safeguard electrical cables, wiring, and hoses from foot and vehicular traffic.

Make/Brand: KTI
Channels: 2 Channels
Channel Dimensions: 35 mm (Width) x 35 mm (Height)
Overall Dimensions: 1000 mm (L) x 240 mm (W) x 45 mm (H)
Material: Vulcanised rubber base with durable plastic lid
Unit Weight: Approx. 5.5 kg
Application: Industrial floor cable management, factory shop floors, warehouses, construction sites, and event venues

KTI160040012CHP

4.5

8 ratings

Price

₹ 1,944.00 excl. GST

+ 18.00% Tax + Freight Charge

If you are an existing KTI Customer, Sign In to view your special price

Product Details
Available Brands	KTI
Unit	Numbers
HSN Code	39269099
Weight	5.5 kg
Dimension	L 100 x W 24 x H 4.5 cm cm ft in m
Warranty	Not Applicable
Video Link
Resources	Download Datasheet
Tags/categories	Safety Road Traffic Safety Solutions Cable Protector

Usually dispatched within 6 days

About this product .

The 2-Channel Cable Protector (45 mm Height) is engineered to provide reliable mechanical protection for temporary and permanent electrical cables, data conduits, and fluid hoses against pedestrian and vehicular traffic.
Manufactured using a durable combination of a heavy-duty rubber base and a rugged plastic hinged top cover, this protector withstands regular compression, abrasion, and outdoor environmental exposure without cracking or deforming.
Featuring two distinct internal channels measuring 35 mm wide by 35 mm high, the unit enables parallel routing and isolation of power and signal lines, reducing cross-talk and preventing accidental tripping or crushing hazards.
The top surface features a textured anti-slip grip profile to maintain safe pedestrian foot traction and prevent vehicular slippage in both dry and wet operational environments.
With an overall length of 1000 mm, standard modular interlocking ends allow multiple units to be connected in series to cover extended spans across pathways, shop floors, and roadways.
This cable protector is ideal for industrial plants, manufacturing units, warehouse loading zones, public event venues, parking structures, and construction sites requiring rapid deployment and dependable safety compliance.

Customer reviews

4.5 out of 5

8 global ratings

5 star

50%

4 star

50%

3 star

2 star

1 star

No customer reviews yet. Be the first to share your experience.

Product Information .

Industries, Factories Hospitals, Clinics Shopping Malls, Showrooms Public Roads Conference Rooms Construction, Builder Projects Server Rooms Basement, Parking Areas Construction Sites

Cable, Utility, and Substrate Compatibility Guide

Cable Geometry and Dimension Tolerances

The KTI KTI160040012CHP 2-Channel Cable Protector is engineered to house, isolate, and shield utility lines across industrial and commercial floor spaces. The unit features two discrete, parallel internal routing cavities, each measured with a cross-sectional profile of 35 mm in width and 35 mm in height. To maintain proper mechanical seating and ensure the top protective structure closes flush, routed conductors, hoses, or bundled lines must not exceed an outside diameter (OD) of 35 mm per channel.

The dual-duct geometry allows facility engineers to isolate distinct utility lines within a single footprint. Top-access loading simplifies integration, enabling operators to place pre-terminated lines directly into the 35 mm x 35 mm channels without disconnecting plugs or pulling long assemblies through closed end orifices.

Electrical Distribution and Power Cabling

This cable protector accommodates standard heavy-duty electrical conductors commonly deployed in temporary and permanent installations, including:

Three-Phase Industrial Drop Cords: Multi-core rubber-sheathed flexible cables supplying machinery, distribution panels, and mobile industrial plant equipment.
Heavy-Duty Extension Leads: High-amperage site power cables used across construction sites, workshops, and fabrication yards.
Temporary Site Power Distribution: Armored and unarmored electrical feeds operating within the 35 mm profile threshold for outdoor event generators, temporary lighting arrays, and distribution kiosks.

Low-Voltage Data, AV, and Fiber Infrastructure

The dedicated twin-channel layout allows complete physical segregation of low-voltage communication cabling from high-voltage AC conductors to prevent electromagnetic interference in sensitive commercial or IT environments:

Data and Network Infrastructure: Bundles of Category-rated copper Ethernet cables (Cat5e, Cat6, Cat6A) and ruggedized indoor/outdoor fiber optic trunk lines for server rooms, IT data centers, and temporary office setups.
Audio-Visual and Stage Multicores: Heavy audio multicore snakes, DMX lighting control lines, and SDI broadcast video feeds across trade shows, concert venues, conferences, and exhibitions.

Pneumatic Hoses and Mechanical Conduit

In addition to electrical wiring, the 35 mm x 35 mm channels accommodate industrial mechanical utility runs. The rubber and plastic composite profile protects flexible pneumatic air lines, fluid delivery hoses, and flexible conduits from mechanical crushing caused by foot traffic and rolling equipment.

Substrate and Facility Deployment Environments

The KTI160040012CHP features an overall footprint of 1000 mm in length, 240 mm in width, and a low-profile 45 mm height with a total unit weight of 5.5 kg. The surface-molded ramp profile facilitates smooth transitions for pedestrian foot traffic and light wheeled crossover. The unit is directly compatible with flat, solid substrates across a range of operational environments:

Industrial production floors, distribution facility walkways, and warehouse aisles.
Commercial office hallways, basements, and server room floor grids.
Hospital corridors, healthcare clinics, and commercial facility thoroughfares.
Covered walkways and flat asphalt or concrete parking access areas.

Application Scenarios & Deployment Environments for KTI 2-Channel Cable Protectors

The KTI KTI160040012CHP 2-Channel Cable Protector (1000 mm x 240 mm x 45 mm) is engineered to isolate and shield surface-laid utilities across industrial, commercial, and temporary event infrastructure. Built with dual 35 mm x 35 mm internal routing cavities and a 5.5 kg rubber-and-plastic composite structure, this profile provides a rigid crossover ramp for high-traffic zones where exposed cables, data trunks, and pneumatic feeds present trip hazards or risk mechanical crushing.

Industrial Facilities, Production Lines & Warehouses

Manufacturing and logistics environments frequently require power drops and process lines to cross open pedestrian aisles and internal transport corridors. The KTI160040012CHP accommodates:

Three-Phase Industrial Power Feeds: Safely routing flexible 3-phase drop cords and heavy-duty power cables (up to 35 mm outside diameter) between distribution boards and floor-mounted machinery.
Pneumatic Air Lines: Shielding flexible pneumatic supply hoses from compression and accidental crimping along active assembly lines and maintenance bays.
Logistics Walkways: Placing modular sections end-to-end along high-traffic warehouse floor walkways to ensure pedestrian safety and unhindered movement of lightweight rolling equipment over floor-laid lines.

Construction Sites & Temporary Electrical Distribution

On construction and civil refurbishment sites, temporary wiring networks are exposed to heavy dynamic foot traffic, grit, and structural abrasion. The composite rubber/PVC blend offers resilience on hard substrate floors. Key site deployment roles include:

Temporary Site Power Management: Housing heavy-duty extension leads and sub-distribution supply runs traversing active work zones.
Modular Pathway Protection: Rapidly establishing continuous linear protective tracks over concrete and compacted surfaces via modular end-to-end alignment.
Top-Access Rapid Relocation: Enabling site electricians to add, inspect, or retrieve conductors via top-access loading without dismantling existing cable terminations or pulling lines through enclosed conduits.

Events, Conferences, Trade Shows & Entertainment Venues

Temporary venue installations require clean, low-profile cable management that blends floor safety with rapid setup and teardown cycles. Typical event applications include:

AV and Stage Production: Enclosing sensitive audio multicore snakes, high-voltage lighting harnesses, and DMX control lines at concert stages, trade show halls, and outdoor festival grounds.
Public Thoroughfares: Providing a surface-molded ramp profile across exhibition hall walkways and conference entrance corridors to prevent attendee trip hazards.

Commercial Hallways, Healthcare Facilities & IT Data Centers

Beyond heavy industrial settings, the unit’s 45 mm profile and dual-channel layout support structured cabling management across sensitive commercial facilities:

Data Centers & Server Rooms: Safeguarding structured networking fiber runs and temporary patching cables across server room aisles and raised floor transitions.
Healthcare & Institutional Corridors: Managing emergency power conduits and diagnostic equipment cables across hospital hallways, clinics, basements, and parking access areas without disrupting gurney or foot traffic.

Use-Case Compatibility Matrix

Operational Environment	Primary Media Protected	Channel Capacity Utilization	Deployment Mode
Industrial Plant / Workshop	3-Phase drop cords, pneumatic hoses	Dual lines up to 35 mm OD	Fixed walkway crossover
Construction & Worksites	Heavy-duty site power distribution lines	Dual runs up to 35 mm OD	Modular continuous line
Events & Trade Shows	Audio multicore snakes, stage lighting cables	Dual bundles up to 35 mm x 35 mm	Temporary high-traffic runs
IT & Commercial Facilities	Data trunks, network fiber, power leads	Dual bundles up to 35 mm x 35 mm	Top-loaded hallway runs
