What is the product Cable Protector also known as? Cable Cover, Cable Ramp, Cord Protector, Wire Protector, Cable Management Ramp, Electrical Cable Cover, Wire Management Protector, Cable Pathway, Floor Cable Protector, Cord Safety Ramp, Heavy-Duty Cable Protector, Cable Guard, Power Cord Protector, Safety Cable Cover, Cable Shield Q: What is a cable protector?

A cable protector, also known as a cable ramp or cable cover, is a device designed to protect cables, hoses, and wires from damage caused by pedestrian or vehicular traffic. It provides a safe and organized way to route and secure cables in areas where they are exposed and prone to potential tripping hazards or accidental damage.

What are the benefits of using cable protectors?

Using cable protectors offers several benefits, including: Safety: Cable protectors help prevent tripping accidents by keeping cables neatly organized and out of the way of foot traffic or vehicles. Cable protection: They provide a physical barrier to shield cables from being stepped on, crushed, or damaged by heavy vehicles or equipment. Easy installation: Cable protectors are typically lightweight and easy to install. They often feature modular designs that allow for quick setup and reconfiguration as needed. Durability: They are made from sturdy materials, such as rubber or polyurethane, which can withstand heavy loads, extreme weather conditions, and frequent use. Versatility: Cable protectors come in various sizes, shapes, and load capacities to accommodate different cable types and traffic volumes. They can be used indoors or outdoors, in temporary or permanent installations.

Where can cable protectors be used?

Cable protectors can be used in a wide range of settings, including: Events and exhibitions: Cable protectors help manage and protect cables used for audio, video, and lighting setups in concert venues, trade shows, and conferences. Construction sites: They are used to secure cables and wires used for power distribution, temporary lighting, or equipment operation in construction zones. Industrial facilities: Cable protectors are employed in manufacturing plants, warehouses, and distribution centers to safeguard cables running across floors or aisles where forklifts, pallet jacks, or other vehicles operate. Public areas: They can be installed in shopping malls, airports, train stations, or public walkways to ensure the safety of pedestrians and prevent tripping hazards caused by exposed cables.

Product Information

Attribute

Value

Channel

1 Channel

Height

20mm

Material

Rubber

Cable Protector 1 Channel Rubber Height 20mm

KTI16004001CR1C

Product Description

The KTI 1-Channel Rubber Cable Protector provides low-profile floor cable management and physical protection for electrical wiring, data cables, and temporary power cords across commercial and industrial environments.

Make / Brand: KTI
Product Reference: KTI16004001CR1C
Channel Configuration: 1 Channel
Material: Vulcanised Rubber
Length: 1000 mm
Width: 100 mm
Overall Height: 20 mm
Channel Width: 75 mm
Channel Height: 15 mm to 20 mm
Function: Cord concealment, floor wire protection, and pedestrian trip hazard mitigation
Suitable Environments: Corporate offices, conference rooms, factories, event halls, and commercial walkways

KTI16004001CR1C

4.4

9 ratings

Price

₹ 999.00 excl. GST

+ 18.00% Tax + Freight Charge

If you are an existing KTI Customer, Sign In to view your special price

Product Details
Available Brands	KTI
Unit	Numbers
HSN Code	40169990
Weight	1.87 kg
Dimension	L 100 x W 10 x H 2 cm cm ft in m
Warranty	Not Applicable
Resources	Download Datasheet
Tags/categories	Safety Road Traffic Safety Solutions Cable Protector

4.00 Nos Ready in Stock Dispatched by Tomorrow, Wed, 16th September

Customer reviews

4.4 out of 5

9 global ratings

5 star

44%

4 star

56%

3 star

2 star

1 star

No customer reviews yet. Be the first to share your experience.

Substrate Type	Application Environment	Placement Recommendation
Finished Concrete & Screed	Light factory floors, workshops, warehouses	Direct self-weighted lay-flat placement; ensure surface is oil-free.
Vitrified Tile & Marble	Corporate offices, meeting rooms, halls	Clean surface thoroughly to prevent lateral movement on high-gloss finishes.
Commercial Carpet	Conference rooms, corporate suites	Position directly over carpet; the 1.87 kg rubber weight maintains firm friction grip.
Temporary Event Flooring	Party plots, banquet setups, exhibitions	Place across high-traffic walkways to shield AV and temporary power cords.

Substrate Type

Application Environment

Placement Recommendation

Finished Concrete & Screed

Light factory floors, workshops, warehouses

Direct self-weighted lay-flat placement; ensure surface is oil-free.

Vitrified Tile & Marble

Corporate offices, meeting rooms, halls

Clean surface thoroughly to prevent lateral movement on high-gloss finishes.

Commercial Carpet

Conference rooms, corporate suites

Position directly over carpet; the 1.87 kg rubber weight maintains firm friction grip.

Temporary Event Flooring

Party plots, banquet setups, exhibitions

Place across high-traffic walkways to shield AV and temporary power cords.

Deployment Environment	Target Cable Types	Primary Operational Objective
Corporate Offices & IT Suites	Power extensions, Cat6 data lines, display cables	Eliminate pedestrian trip hazards; protect cords on carpet/tile
Light Factories & Workshops	Single-phase equipment cords, control wiring	Shield cables from foot traffic and light trolley crossover
Banquet Halls & Party Plots	AV sound cables, stage lighting runs, power leads	Rapid temporary cable concealment and public pathway safety
Exhibition Centres & Booths	Display power wiring, multi-conductor bundles	Organize bundles up to 75 mm wide across temporary booth aisles

Deployment Environment

Target Cable Types

Primary Operational Objective

Corporate Offices & IT Suites

Power extensions, Cat6 data lines, display cables

Eliminate pedestrian trip hazards; protect cords on carpet/tile

Light Factories & Workshops

Single-phase equipment cords, control wiring

Shield cables from foot traffic and light trolley crossover

Banquet Halls & Party Plots

AV sound cables, stage lighting runs, power leads

Rapid temporary cable concealment and public pathway safety

Exhibition Centres & Booths

Display power wiring, multi-conductor bundles

Organize bundles up to 75 mm wide across temporary booth aisles

	Current Product Cable Protector 1 Channel Rubber Height 20mm	Cable Protector 1 Channel Height 120MM	Cable Protector 2 Channel Height 45MM	+ Add product to compare
SKU	KTI16004001CR1C	KTI16004001C112	KTI160040012CHP	—
Brand	KTI	H2, KTI	KTI	—
Price (excl. GST)	₹ 999.00 excl. GST	₹ 4,900.50 excl. GST	₹ 1,944.00 excl. GST	—
GST %	18.00%	18.00%	18.00%	—
Channel	1 Channel	1 Channel	2 Channel	—
Height	20mm	120mm	45mm	—
Material	Rubber	PVC	PVC	—
Certifications	—	—	—	—
Availability	In Stock	Made to Order	Made to Order	—
				—

Current Product

Cable Protector 1 Channel Rubber Height 20mm

Cable Protector 1 Channel Height 120MM

Cable Protector 2 Channel Height 45MM

+ Add product to compare

SKU

KTI16004001CR1C

KTI16004001C112

KTI160040012CHP

—

Brand

KTI

H2, KTI

KTI

—

Price (excl. GST)

₹ 999.00 excl. GST

₹ 4,900.50 excl. GST

₹ 1,944.00 excl. GST

—

GST %

18.00%

—

Channel

1 Channel

2 Channel

—

Height

20mm

120mm

45mm

—

Material

Rubber

PVC

—

Certifications

—

Availability

In Stock

Made to Order

—
