Product Information

Attribute

Value

Height

120mm

Material

PVC

Channel

1 Channel

1 Channel Cable Protector 120MM Height with Rubber Base and PVC Flap

Cable Protector 1 Channel Height 120MM

KTI16004001C112

Product Description

Heavy-duty single-channel cable protector ramp designed to safeguard heavy cables, pipes, and hoses against vehicular drive-over and foot traffic.

Brand / Make: KTI / H2
Model Ref: KTI16004001C112
Number of Channels: 1 Channel
Overall Dimensions: 1000 mm (L) x 580 mm (W) x 120 mm (H)
Channel Dimensions: 75 mm (W) x 120 mm (H)
Base Material: Heavy-duty Rubber
Flap / Lid Material: PVC and Plastic
Installation: Modular floor surface placement for indoor and outdoor roadways
Applications: Manufacturing plants, construction sites, commercial complexes, event grounds, and warehouse pathways

KTI16004001C112

Price

₹ 4,900.50 excl. GST

+ 18.00% Tax + Freight Charge

If you are an existing KTI Customer, Sign In to view your special price

Product Details
Available Brands	KTI, H2
Unit	Numbers
HSN Code	39269099
Weight	22 kg
Dimension	L 100 x W 58 x H 12 cm cm ft in m
Warranty	Not Applicable
Tags/categories	Safety Road Traffic Safety Solutions Cable Protector

Usually dispatched within 4 days

About this product .

The 1-Channel Heavy-Duty Cable Protector is engineered to protect large-diameter electrical cables, pneumatic lines, and fluid hoses from damage caused by heavy vehicle transit and pedestrian traffic in industrial and commercial environments.
Constructed with a dense vulcanized rubber base, the unit provides high surface grip and stability on asphalt, concrete, and industrial flooring. A durable hinged PVC and plastic top flap enables quick and convenient drop-in cable routing without requiring disconnections.
Featuring an oversized single channel measuring 75 mm in width and 120 mm in height, this protector accommodates bulky power conduits, industrial hose lines, and grouped cable harnesses measuring up to 1000 mm per modular section.
The ramp is designed to withstand harsh outdoor conditions, industrial chemicals, grease, and continuous traffic. Its interlocking modular design facilitates end-to-end continuous runs across roadway crossings and warehouse aisles.
Typical deployment scenarios include manufacturing facilities, construction and infrastructure job sites, temporary event grounds, shipping yards, and parking facilities where high ground clearance and cable integrity are critical.
The solid rubber and synthetic plastic assembly requires zero electrical maintenance and can be easily washed or swept clean during routine facility housekeeping.

Product Information .

Industries, Factories Hospitals, Clinics Shopping Malls, Showrooms Public Roads Conference Rooms Construction, Builder Projects Server Rooms Basement, Parking Areas Construction Sites

Cable, Utility, and Facility Compatibility Guidelines

Conductor, Hose, and Cable Diameter Compatibility

The KT Automation 1-Channel Cable Protector (SKU: KTI16004001C112) is engineered with an oversized single conduit channel specifically sized to house heavy-gauge utilities. The internal raceway provides a dedicated channel width of 75 mm and a channel height of 120 mm, allowing facility teams and electrical engineers to route substantial utility lines without mechanical binding.

This raceway profile accommodates a broad spectrum of utility types across industrial and commercial infrastructures, including:

Heavy-Duty Industrial Power Cords: Single large-diameter 3-phase power feeders, generator cables, and high-voltage supply lines.
Multi-Cable Bundles: Grouped low-voltage lines, control cables, power extension runs, and network distribution feeds consolidated within the 75 mm x 120 mm cross-sectional area.
Fluid and Pneumatic Hoses: Industrial air compressor lines, temporary water discharge lines, and hydraulic supply hoses measuring up to 75 mm in outside diameter.
Protective Flexible Conduits: Corrugated plastic conduits and flexible steel armoring used in construction and temporary utility setups.

Surface and Infrastructure Integration

Engineered with an overall unit footprint of 1000 mm in length, 580 mm in width, and 120 mm in height, this cable protector integrates seamlessly into heavy transit environments. Its substantial 580 mm base profile provides structural ground stability when placed directly across pathways, transit aisles, or vehicular crossover points.

The heavy-duty rubber base conforms to various indoor and outdoor ground surfaces without requiring permanent mechanical anchoring. Compatible deployment surfaces include:

Industrial & Logistics Facilities: Polished or sealed concrete warehouse floors, manufacturing workshop transit corridors, and factory loading bays.
Vehicular & Parking Areas: Asphalt surfaces, bitumen roadways, public roads, basement parking lots, and commercial access driveways.
Commercial & Institutional Flooring: Tiled corridors, epoxy floors, and transit zones in hospitals, clinics, shopping malls, and commercial buildings.
Temporary & Site Infrastructure: Compacted gravel, construction project access paths, outdoor event grounds, and server room access routes.

Dimensional & Utility Fit Specifications

Specification Parameter	Dimensional Value / Detail	Integration Scope
Channel Quantity	1 Channel	Dedicated single utility or bundled run
Channel Cross-Section	75 mm (W) × 120 mm (H)	Lines and hoses up to 75 mm × 120 mm profile
Unit External Dimensions	1000 mm (L) × 580 mm (W) × 120 mm (H)	1-meter modular coverage per section
Base Construction	Heavy-Duty Rubber	Surface grip across asphalt, concrete, and subfloors
Flap Construction	PVC and Plastic Composite	Top-opening protective utility closure
HSN Code Classification	39269099	Industrial road traffic safety equipment

Top-Loading Retrofit Compatibility

The integrated top-opening hinged flap, manufactured from a durable PVC and plastic composite, allows rapid retrofitting over pre-existing infrastructure. Technicians can insert or extract cables and hoses directly from the top without disconnecting active power lines, terminating industrial connections, or interrupting plant operations.

Installation and Deployment Guide for 1-Channel Rubber Cable Protector (120mm Height)

Surface Preparation and Deployment Area Assessment

Deploying the 1-channel heavy-duty rubber cable protector begins with assessing the target transit corridor or vehicular crossover point. Ensure the underlying surface across factory floors, warehouse aisles, basement parking lots, public roads, or construction site access routes is clear of major loose debris, stones, and obstructions. The flat rubber base requires continuous, direct contact with the ground plane across its full 1000 mm length and 580 mm width to provide stable placement under transit traffic.

Position the unit perpendicular to the expected directional flow of pedestrian traffic or moving vehicles in facilities such as industrial manufacturing plants, commercial buildings, builder project zones, shopping malls, clinics, and hospitals. Aligning the ramp profile directly against the direction of travel ensures smooth crossover across the 120 mm ramp height profile.

Direct Surface Placement Procedure

The unit is engineered for rapid, non-invasive direct surface placement without requiring complex ground anchor modifications or permanent structural adhesives. Place the heavy-duty rubber base directly onto the asphalt, concrete, screed, or flat subfloor along designated routing pathways. For extended runs spanning across wide driveways, outdoor event spaces, or server room utility tracks, position consecutive 1000 mm modules end-to-end in direct linear alignment to establish continuous channel protection along the entire cable run.

Top-Loading Cable and Hose Insertion Process

The integrated top-opening hinged flap eliminates the need to thread cables or disconnect operational equipment during setup and reconfiguration:

Flap Access: Lift the PVC and plastic composite top flap upwards from the rubber base to expose the entire interior utility channel.
Line Positioning: Lay single cables, bundled power cords, temporary electrical feeds, or industrial fluid hoses directly into the channel bed from above. Pre-terminated lines and continuous runs can be placed immediately without uncoupling fittings or disconnecting junction points.
Capacity Verification: Confirm that the cumulative diameter or bundle cross-section does not exceed the internal channel dimensions of 75 mm in width and 120 mm in height.
Secure Closure: Press the PVC and plastic composite flap firmly back down into its seated recess along the heavy-duty rubber base. Ensure the flap sits flush across the top surface to maintain a uniform crossover profile and fully enclose the lines within the channel.

Application-Specific Deployment Guidelines

In high-density industrial and commercial environments, tailored deployment practices ensure optimal performance and safety:

Construction Sites and Builder Projects: Position across primary vehicle crossover tracks and site plant paths to shield heavy-gauge temporary power cables and site service feeds from impact and abrasion.
Industrial Plants and Warehouses: Lay across high-traffic transit aisles, logistics loading bays, and machinery supply paths to organize floor-routed utilities and prevent trip hazards.
Basement Parking Lots and Driveways: Deploy across entrance aprons, ramp junctions, and vehicle driveways where surface power routing crosses active vehicle lanes.
Hospitals, Clinics, and Commercial Centers: Install along maintenance corridors, event stages, temporary facility additions, and server rooms to route heavy data and power lines cleanly across pedestrian walking zones.

Dimensional and Channel Fit Matrix

Specification Parameter	Dimension / Standard	Installation Consideration
Overall Length	1000 mm	Modular unit length for calculating linear coverage across transit spans
Overall Width	580 mm	Total footprint width providing gradual transition for pedestrian and vehicular traffic
Overall Height	120 mm	Total vertical profile height across the crest of the unit
Number of Channels	1 Channel	Single dedicated internal raceway for consolidated utility routing
Channel Width	75 mm	Maximum allowable width for single or bundled cables and hoses
Channel Height	120 mm	Internal clearance height for heavy-duty industrial lines
Base Material	Heavy-duty rubber	Direct contact foundation providing surface grip and ground conformity
Flap Material	PVC and plastic composite	Top-hinged access lid for fast top-loading insertion and line inspection
Customs Tariff / HSN	39269099	Standard industrial classification for logistics and procurement reference

Industrial and Commercial Applications for 1-Channel 120mm Cable Protectors

The KT Automation H2 1-Channel 120MM Cable Protector (SKU: KTI16004001C112) is engineered to shield high-capacity utility lines, hoses, and electrical lines from physical impact and vehicular compression. Measuring 1000 mm in length, 580 mm in width, and 120 mm in height, this protector provides an internal 75 mm wide by 120 mm high channel capable of managing large-diameter single cables or consolidated conduit bundles across high-traffic environments.

Construction Sites and Builder Infrastructure Projects

Active construction sites and infrastructure developments require robust mechanical protection for heavy-duty power lines, pneumatic hoses, and temporary water lines. The rubber base provides high-friction ground contact, while the top-loading PVC and plastic composite flap allows work crews to drop in and retrieve supply lines across dynamic work zones without disconnecting power sources. It safeguards essential lines from direct contact with site vehicles, machinery crossings, and worker transit routes.

Industrial Plants, Factories, and Warehouse Floors

Manufacturing plants and logistics warehouses experience constant cross-traffic from industrial vehicles, pallet equipment, and personnel across interior transit aisles. Placing these 1000 mm modular cable units across internal roads and floor pathways prevents critical wiring harnesses and process supply cords from crushing or pinch damage. The 75 mm channel width easily accommodates bulky industrial power lines, maintaining uninterrupted operations across assembly lines and distribution lanes.

Basement Parking Lots, Driveways, and Public Roadways

In vehicular management sectors, managing utility runs across driveways, parking ramps, and road crossings demands stable, road-traffic-ready enclosures. This 120 mm high profile acts as a protective conduit bridge in basement parking areas, public road access lanes, and commercial entry gates, allowing vehicles to traverse power lines safely without severing or compressing internal wires.

Commercial Buildings, Hospitals, and Healthcare Clinics

Commercial complexes, clinical facilities, and hospital campuses often require temporary or retrofitted power feeds across service passages and access corridors. Utilizing this cable protector prevents heavy equipment, utility carts, and maintenance traffic from compromising critical communication cords and power lines, keeping floor transitions organized and fully protected.

Temporary Power Routing for Outdoor Events and Server Rooms

Temporary utility installations for outdoor venues, event staging, and facility server rooms require rapid cable deployment and fast turnaround times. The top-opening hinged flap allows technicians to quickly configure or alter temporary line runs up to 120 mm in height without threading lines through enclosed pipes, ensuring rapid setup and secure operational shielding.

Related Products .

Page 1 of 4

Syncing...

Compare with similar products .

	Current Product Cable Protector 1 Channel Height 120MM	Cable Protector 1 Channel Plastic Height 35mm	Cable Protector 3 Channel Height 75MM	+ Add product to compare
SKU	KTI16004001C112	KTI16004001CP2C	KTI160040013CH8	—
Brand	H2, KTI	KTI	Axnoy	—
Price (excl. GST)	₹ 4,900.50 excl. GST	₹ 1,458.00 excl. GST	₹ 3,429.00 excl. GST	—
GST %	18.00%	18.00%	18.00%	—
Channel	1 Channel	1 Channel	3 Channel	—
Height	120mm	30mm	75mm	—
Material	PVC	Plastic	PVC - Rubber	—
Certifications	—	—	—	—
Availability	Made to Order	Made to Order	Made to Order	—
				—

Category FAQ .

Cable Protector

A cable protector, also known as a cable ramp or cable cover, is a device designed to protect cables, hoses, and wires from damage caused by pedestrian or vehicular traffic. It provides a safe and organized way to route and secure cables in areas where they are exposed and prone to potential tripping hazards or accidental damage.

Using cable protectors offers several benefits, including: Safety: Cable protectors help prevent tripping accidents by keeping cables neatly organized and out of the way of foot traffic or vehicles. Cable protection: They provide a physical barrier to shield cables from being stepped on, crushed, or damaged by heavy vehicles or equipment. Easy installation: Cable protectors are typically lightweight and easy to install. They often feature modular designs that allow for quick setup and reconfiguration as needed. Durability: They are made from sturdy materials, such as rubber or polyurethane, which can withstand heavy loads, extreme weather conditions, and frequent use. Versatility: Cable protectors come in various sizes, shapes, and load capacities to accommodate different cable types and traffic volumes. They can be used indoors or outdoors, in temporary or permanent installations.

Cable protectors can be used in a wide range of settings, including: Events and exhibitions: Cable protectors help manage and protect cables used for audio, video, and lighting setups in concert venues, trade shows, and conferences. Construction sites: They are used to secure cables and wires used for power distribution, temporary lighting, or equipment operation in construction zones. Industrial facilities: Cable protectors are employed in manufacturing plants, warehouses, and distribution centers to safeguard cables running across floors or aisles where forklifts, pallet jacks, or other vehicles operate. Public areas: They can be installed in shopping malls, airports, train stations, or public walkways to ensure the safety of pedestrians and prevent tripping hazards caused by exposed cables.
