CONTROLLER for PA System
KTI16017002CONT
Product Description
Controller
Make: Bosch
Model no:LBB1990/00
Heart of the Plena Voice Alarm System
EN 54‑16 certified
Built-in message manager and 240 W amplifier
Six‑zone outputs
6 emergency and 6 business triggers
Voltage 230/115VAC, ±15%, 50/60 Hz
Current inrush 8 A
Max power consumption 600 VA
Voltage 24 VDC, +15% / -15%
Current max 14 A
Output power (rms/maximum) 240 W / 360 W
Power reduction on backup power -1 dB
Frequency response 60 Hz to 18 kHz (+1/-3 dB at -10 dB ref. rated output)
Distortion 1 kohm (mic); >5 kohm (line)
S/N (flat at max volume) >63 dB (mic); >70 dB (line)
S/N (flat at min volme/muted) >75 dB
CMRR >40 dB (50 Hz - 20 kHz)
Headroom >25 dB
Speech filter -3 dB at 315 Hz, high-pass, 6 dB/oct
Dimensions (H x W x D) 144 x 430 x 370 mm
(19" wide, 3U high)
Weight Approx. 21.17 kg
Mounting 19”rack
Color Charcoal
Make: Bosch
Model no:LBB1990/00
Heart of the Plena Voice Alarm System
EN 54‑16 certified
Built-in message manager and 240 W amplifier
Six‑zone outputs
6 emergency and 6 business triggers
Voltage 230/115VAC, ±15%, 50/60 Hz
Current inrush 8 A
Max power consumption 600 VA
Voltage 24 VDC, +15% / -15%
Current max 14 A
Output power (rms/maximum) 240 W / 360 W
Power reduction on backup power -1 dB
Frequency response 60 Hz to 18 kHz (+1/-3 dB at -10 dB ref. rated output)
Distortion 1 kohm (mic); >5 kohm (line)
S/N (flat at max volume) >63 dB (mic); >70 dB (line)
S/N (flat at min volme/muted) >75 dB
CMRR >40 dB (50 Hz - 20 kHz)
Headroom >25 dB
Speech filter -3 dB at 315 Hz, high-pass, 6 dB/oct
Dimensions (H x W x D) 144 x 430 x 370 mm
(19" wide, 3U high)
Weight Approx. 21.17 kg
Mounting 19”rack
Color Charcoal
Read More
| Available Brands | Bosch |
|---|---|
| Unit | Numbers |
| HSN Code | 85423300 |
| Weight | 21.17 kg |
| Warranty | 12 Months No-Onsite Warranty |
| Resources | |
| Tags/categories |
Enter number of units to add to cart.
Usually dispatched within 2 days
